Product Description: UL KG 9600 is a low-odor, two-component aliphatic polyurea spray coating designed as a UV-stable topcoat for polyurea and polyurethane systems. It is 100% solids, VOC-free, environmentally friendly, and features excellent color, gloss retention, and UV stability.
Application Equipment: High Volume Low Pressure (HVLP) spray system with a 1.8 spray tip. Both the Isocyanate “A” Side and Resin “B” Side must be preconditioned between 70°F to 90°F before spraying.
Ratio: 1:1 by volume
Gel Time: 30-45 minutes pot life; tack free in 10-15 minutes
Basic Physical Properties:
Adhesion: 535 psi (ASTM D4541)
Elongation: 60% (ASTM D412)
Flexibility: Pass, no cracking (1/8 Mandrel, ASTM D522)
Gloss Retention: 81+ (ASTM D523)
Hardness: 46 ± 2 Shore D (ASTM D2240)
Impact Resistance: 32 in-lbs (ASTM D2794)
QUV Topcoat: Delta E <2.0 @ 1,700 hrs (ASTM G154)
Taber Abrasion: 30.5 mg loss (ASTM D4060)
Tensile Strength: 1,287-1,441 psi (ASTM D412)
Key Certifications: Complies with FDA and USDA Coating Regulations for Incidental Food Contact Applications (Keller and Heckman LLP Letter of Opinion).
Recommended Applications: Ideal for topcoats on truck bedliners and other Ultimate Linings polyurea systems. Suitable for substrates like aluminum, galvanized steel, and fiberglass with appropriate preparation.
Packaging:
- 2-gallon set: 1 gallon Part-A (Isocyanate side) and 1 gallon Part-B (Resin side)
